E2000,LC,SC,FC,ST Fiber optic jumper patch cable patch cord

Product Description

Telsto Fiber Optic Patch Cords are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. Refer to the diagram above for dimensional information. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic/phosphor bronze alignment sleeves and a precision moulded polymer housing provides consistent long-term mechanical and optical performance.

1.Price-Competitive

2.Low Insertion Loss & PDL

3.Factory-terminated and Tested

4.Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber

5.Connector Options: FC/SC/LC/ST/MU/E2000/MT-RJ/MPO/MTP

6.Polishing Options: PC/UPC/APC

7.Feature Connector with Ceramic Ferrules

Applications


1.Access Network

2.Telecom/CATV Systems

3.FTTx

Specifications


Parameters Standard Fiber Cable Assemblies
Fiber Type SM(G.652/G.657A) MM(OM1/OM2/OM3)
Jacket Materials LSZH/OFNR/PVC
Connector Type SC/LC/ST/LC/MU/MTRJ/MPO/E2000
Ferrule Materials Ceramic
Testing Wavelengths 1310±30/1550±30nm 850±30/1300±30nm
Insertion Losss(dB)
TIA/EIA-455-107
≤ 0.3dB
(PC/UPC/APC)
≤ 0.3dB
(PC/UPC)
Return Loss(dB)
TIA/EIA-455-107
≥45dB(PC/UPC)
≥55dB(APC)
≥35dB(PC/UPC)
Exchangeability ≤ 0.2dB
Cable Assemblies Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (° C) -10~ + 70
Storage Temperature (° C) -40 ~ +85
Package 1unit/bag
*All values specified are with connectors.

Quick Details


Place of Origin:shanghai, China (Mainland)
Brand Name:Telsto
Model Number:Patch cord
Product name:fiber optic patch cord
Inserion Loss:<0.2db
Return Loss:>50db
Fiber Type:Single Mode and multi mode
Jacket color:Yellow
length:customize
Application:FTTH FTTB FTTX Network
Material:PVC,LSZH

Features


1.Price-Competitive

2.Low Insertion Loss & PDL

3.Factory-terminated and Tested

4.Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber

5.Connector Options: FC/SC/LC/ST/MU/E2000/MT-RJ/MPO/MTP

6.Polishing Options: PC/UPC/APC

7.Feature Connector with Ceramic Ferrules
