LC APC to LC UPC, SM, Duplex, 2.0MM, 3M, LSZH, 9/125, OS2 Fiber Optic Patch Cord

Product Description

Fiber Optic Patch Cables, LC/LC, Singlemode, various lengths.

Telsto Fiber Optic Patch Cords are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. Refer to the diagram above for dimensional information. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic/phosphor bronze alignment sleeves and a precision moulded polymer housing provides consistent long-term mechanical and optical performance.


- Duplex cable
- Connector with ceramic ferrule
- Cable diameter: 2.0 mm

- Cable length: 3m
- Connector 1:LC APC; Connector 2:LC UPC
- Mode: Singlemode
- Fiber classes: OS2, 9/125 μ;

- Package: polybag with sticker

Product Overview

Telsto offers a wide range of high quality fiber optic patch cables. Practically every request and every
requirement is covered by the broad range of cable types. The product range includes OM1, OM2, OM3 and
OS2 versions. Telsto fiber optic installation cables guarantee the best performance and fail-safety.
All cables are single packed a polybag with test report.


Telecommunications, Cable TV
Sensor technologies
Medical instrumentation and measurement techniques
Industrial applications

Technical performance

Cable Diameter: 2.0mm

Insertion Loss: ≤ 0.3dB

Return Loss: ≥ 50dB

Operating temperature: -40℃ up to +75℃

Storage temperature:-40℃ up to +75℃

Quick Details

Place of Origin:shanghai, China (Mainland)
Brand Name:Telsto
Connector:LC, LC
Polishing:LC APC,LC UPC
Transfer Mode:Single mode
Fiber classes:OS2, 9/125 μ
Cable length:3m
